SMART Board M600ix3 - Page 40

CHAPTER 4
MAINTAINING THE INTERACTIVE WHITEBOARD SYSTEM
32 smarttech.com/kb/170910
4. Open the lamp cover.
5. Use a Phillips screwdriver to loosen the two captive screws from the bottom of the lamp
module.
NOTE
Don’t try to remove these screws. Captive screws can’t be removed, only loosened.
6. Pull up the lamp handle carefully.
