APPENDIX B
REMOTELY MANAGING THE SYSTEM THROUGH AN RS-232 SERIAL INTERFACE
84 smarttech.com/kb/170910
Field
Possible Values
Description
current testpattern
l
1: 19 × 25 Grid
l
2: Red
l
3: Green
l
4: Blue
l
5: Grey
l
6: White
l 7: Black
Test pattern being displayed. The built-in test
pattern can be changed.
target colorwheelidx = ??? The ranges must match the OSD ranges.
current colorwheelidx ??? The ranges must match the OSD ranges.
