Smartgen HGMS61 User Manual

HGMS61 Genset Controller User Manual Page 46 of 47
13.19 WEICHAI
It is suitable for Weichai BOSCH common rail pump engine.
Table 44 – Engine Port
Terminals of controller
Engine port
Remark
Fuel relay output
1.40
Set configurable output 1 as “Fuel Relay
Output”.
Connect to engine ignition lock
Start relay output
1.61
-
CAN communication shielding line
CAN(H)
1.35
Using impedance 120Ω connecting line
CAN(L)
1.34
Using impedance 120Ω connecting line
Engine type: GTSC1
