Smartgen HGMS61 User Manual

HGMS61 Genset Controller User Manual Page 8 of 47
3 SPECIFICATION
Table 4 – Performance Parameters
Items
Contents
Working Voltage
Range: DC8.0V~DC35V, continuous power supply, DC reverse
protection
Resolution: 0.1V
Accuracy: 1%
Power Consumption
<7W(Standby mode: ≤2.5W)
AC Voltage
Phase voltage
Range: AC15V~AC360V(ph-N)
Resolution: 1V
Accuracy: 1%
Line voltage
Range: AC30V~AC620V(ph-ph)
Resolution: 1V
Accuracy: 1%
AC Frequency
Range: 5Hz~75Hz
Resolution: 0.1Hz
Accuracy: 0.1Hz
AC Current
Rated: 5A
Range:0A~10A
Resolution: 0.1A
Accuracy: 1%
Speed Sensor
Voltage Range: 1.0V ~ 24V (RMS)
Frequency Range: 5Hz~10000Hz
Charger(D+) Voltage
Range: DC0V~DC60V continuous power supply
Resolution: 0.1V
Accuracy: 1%
Analog Sensor
Resistance input
Range: 0Ω ~ 6000Ω
Resolution: 0.1Ω
Accuracy:1Ω（below 300Ω）
Fuel Relay Output
10A DC30V DC supply output (relay output, pluggable)
Start Relay Output
10A DC30V DC supply output (relay output, pluggable)
Digital Output 1
7A DC24V DC supply output (relay output)
Digital Output 2
10A AC250V volt-free output (relay output)
Digital Output 3
16 A AC250V volt-free output (relay output)
Digital Output 4
16 A AC250V volt-free output (relay output)
Digital Input 1~4
Low on threshold voltage: 1.2V, Max. input voltage: 60V
RS485
Isolated, half-duplex, 9600 baud rate,
maximum communication length 1000m

Smartgen HGMS61 Specifications

General

Brand	Smartgen
Model	HGMS61
Category	Controller
Language	English
