HGMS61 Genset Controller User Manual Page 43 of 47
13.12 MTU ADEC (SAM MODULE)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Table 34 – ADEC (X1 port)
Terminals of controller
ADEC (X1port)
Remark
Programmable output1
X1 43
Set configurable output 1 as “Fuel Relay
Output”.
X1 Terminal 28 Connected to negative of
battery
Start relay output
X1 37
X1 Terminal 22 Connected to negative of
battery
Table 35 – SAM (X23 port)
Terminals of controller
SAM (X23 port)
Remark
X23 3
CAN communication shielding line
CAN(H)
X23 2
Using impedance 120Ω connecting line
CAN(L)
X23 1
Using impedance 120Ω connecting line
Engine type: Common J1939
13.13 PERKINS
It is suitable for ADEM3/ ADEM4 engine control mode. Engine type is 2306, 2506, 1106, and 2806.
Table 36 - Connector
Terminals of controller
Connector
Remark
Programmable output1
1,10,15,33,34
Set configurable output 1 as “Fuel Relay
Output”.
Start relay output
-
Connect to starter coil directly
-
CAN communication shielding line
CAN(H)
31
Using impedance 120Ω connecting line
CAN(L)
32
Using impedance 120Ω connecting line
Engine type: PERKINS
13.14 SCANIA
It is suitable for S6 engine control mode. Engine type is DC9, DC12, and DC16.
Table 37 – B1 Connector
Terminals of controller
B1 connector
Remark
Programmable output1
3
Set configurable output 1 as “Fuel Relay
Output”
Start relay output
-
Connect to starter coil directly
-
CAN communication shielding line
CAN(H)
9
Using impedance 120Ω connecting line
CAN(L)
10
Using impedance 120Ω connecting line
Engine type: SCANIA
