HGMS61 Genset Controller User Manual Page 39 of 47
13.3 CUMMINS QSM11 (IMPORT)
It is suitable for CM570 engine control mode. Engine type is QSM11 G1, QSM11 G2.
Table 21 – C1 Connector
Terminals of controller
C1 connector
Remark
Programmable output1
5&8
Set configurable output 1 as “Fuel Relay
Output”. Outside expand relay, when fuel
output, making port 5 and port 8 of C1 be
connected
Start relay output
-
Connect to starter coil directly
Table 22 – 3 Pins Data Link Connector
Terminals of controller
3 pins data link connector
Remark
C
CAN communication shielding line(connect
to ECU terminal only)
CAN(H)
A
Using impedance 120Ω connecting line
CAN(L)
B
Using impedance 120Ω connecting line
Engine type: CUMMINS-ISB
13.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Table 23 – 50 Pins Connector
Terminals of controller
50 pins connector
Remark
Programmable output1
38
Oil spout switch; Set configurable output 1
as “Fuel Relay Output”.
Start relay output
-
Connect to starter coil directly
Table 24 – 9 Pins Connector
Terminals of controller
9 pins connector
Remark
SAE J1939 shield-E
CAN communication shielding line(connect
to ECU terminal only)
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line
Engine type: CUMMINS -CM570
