HGMS61 Genset Controller User Manual Page 13 of 47
4.4 MANUAL START/STOP OPERATION
a) Manual Mode is active when press and its indicator illuminates. Press to start genset,
it can automatically detect crank disconnect and accelerate to high speed running. If there is high
water temperature, low oil pressure, over speed and abnormal voltage during genset running,
controller can protect genset to stop (detailed procedures please refer to No.c~h of Auto Start
Operation). After genset runs normally in high speed, press and gens take load.
b) Manual Stop: pressing can shut down the running genset (detailed procedures please refer to
No.b~f of Auto Stop Operation).
4.5 EMERGENCY START
In manual mode, pressing and can force genset to start. The controller won’t judge
whether the controller has started successfully according to disconnect conditions and the disconnection
of starter needs to be controlled by operators. When operators observe the genset has started
successfully, after loosening the keys, the start relay disconnects and then the controller enters safety
delay.
5 PROTECTION
5.1 WARNINGS
When controller detects the warning signal, the controller only alarms but not stop.
Table 7 – Controller Warning Alarms
No.
Warnings
Description
1
Loss Of Speed Signal
When the speed of genset is 0 and speed loss delay is 0, controller will
send warning alarm signal and it will be displayed on LCD.
2
Gen Over Current
When the current of genset is higher than threshold and setting over
current delay is 0, controller will send warning alarm signal and it will be
displayed on LCD.
3
Fail To Stop
When ‘ETS solenoid hold’ /’Fail to stop’ is over, controller will send
warning alarm signal and it will be displayed on LCD.
4
Low Fuel Level
When the fuel level of genset is lower than threshold or low fuel level
warning input is active, controller will send warning alarm signal and it
will be displayed on LCD.
5
Failed To Charge
During genset normal running process, when the voltage difference
between B+ and the charger D+ (WL) is above the Failed To Charge
voltage difference for 5s, the controller will send Failed To Charge
warning and it well be displayed on LCD.
6
Battery Under Voltage
When the battery voltage of genset is lower than threshold, controller will
