HGMS61 Genset Controller User Manual Page 38 of 47
13 CONNECTIONS OF CONTROLLER WITH J1939 ENGINE
13.1 CUMMINS ISB/ISBE
Table17 – Connector B
Terminals of controller
Connector B
Remark
Programmable output port 1
39
Set configurable output 1 as “Fuel Relay
Output”
Start relay output
-
Connect with starter coil directly
Programmable output port 2
Expand 30A relay,
battery voltage of
01,07,12,13 is supplied
by relay.
ECU power
Set configurable output 2 as “ECU power”
Table 18 – 9 Pins Connector
Terminals of controller
9 pins connector
Remark
SAE J1939 shield
CAN communication shielding line(connect
to ECU terminal only)
CAN(H)
SAE J1939 signal
Using impedance 120Ω connecting line.
CAN(L)
SAE J1939 return
Using impedance 120Ω connecting line.
Engine type: CUMMINS-ISB
13.2 CUMMINS QSL9
Suitable for CM850 engine control mode.
Table 19 – 50 Pins Connector
Terminals of controller
50 pins connector
Remark
Programmable output port
1
39
Set configurable output 1 as “Fuel Relay
Output”
Start relay output
-
Connect to starter coil directly
Table 20 – 9 Pins Connector
Terminals of controller
9 pins connector
Remark
SAE J1939 shield-E
CAN communication shielding line(connect
to ECU terminal only)
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line
Engine type: CUMMINS-CM850
