HGMS61 Genset Controller User Manual Page 6 of 47
1 OVERVIEW
HGMS61 Genset Controller adopts split structure of “Master Control and Display”, integrating
digital, intelligent and network techniques, is used for automatic control and monitoring system of
genset. It can carry out functions of automatic start/stop, data measurement, alarm protection and
“four remote” (remote control, remote measure, remote communication and remote adjustment). The
controller uses monochrome LCD display, optional interface with multiple languages, which is easy and
reliable to operate.
HGMS61 Genset Controller uses 32-bit microprocessor technique which can achieve precision
measurement, value adjustment, timing and threshold setting etc.. All the parameters can be
configured from front panel or use USB interface (or RS485 interface) to adjust via PC. Its equipped
fuse, fuel and start relay are pluggable. The compact structure and simple wiring of the controller solve
the problem of complex wiring and low efficiency, and improve the production efficiency of the control
cabinet. It can be widely used in various types of automatic control system.
2 PERFORMANCE AND CHARACTERISTICS
HGMS61: HGMS61D+HGMS61M； HGMS61CAN: HGMS61D+HGMS61MCAN.
Display Module: HGMS61D, Master Control Module: HGMS61M, HGMS61MCAN.
HGMS61D: Display control module.
HGMS61M: MPU interface, suitable for ESC controlled engines.
HGMS61MCAN: CAN BUS interface, suitable for ECU controlled J1939 engines.
Note: HGMS61 is taken as an example for following descriptions.
Its main features are as follows:
— 132x64 resolution LCD with backlight, optional language interface (Chinese, English, Spanish,
Russian, Portuguese, Turkey, Polish and French), can be selected through the panel, which is
convenient for debugging personnel;
— With RS485 communication port, can achieve “four remote” functions (remote control, remote
measure, remote communication and remote adjustment) via MODBUS protocol;
— Adapt to 3P4W, 3P3W, 1P2W and 2P3W (120V/240V), 50Hz/60Hz AC power system;
— Can measure and display 3-phase voltage, 3-phase current, frequency, power parameter of gens;
— With over/under voltage, over/under frequency, over current and over power functions of Gens.
