HGMS61 Genset Controller User Manual Page 45 of 47
13.17 VOLVO-EMS2
Volvo Engine types are TAD734, TAD940, TAD941, TAD1640, TAD1641, and TAD1642.
Table 41 – Engine CAN Port
Terminals of controller
Engine’s CAN port
Remark
Programmable output1
6
ECU stop
Configurable output 1 “ECU stop”
Programmable output2
5
ECU power
Configurable output 2 “ECU power”
3
Negative power
4
Positive power
-
CAN communication shielding line
CAN(H)
1(Hi)
Using impedance 120Ω connecting line
CAN(L)
2(Lo)
Using impedance 120Ω connecting line
Engine type: VOLVO-EMS2
Note: When this engine type is selected, preheating time should be set to at least 3 seconds.
13.18 YUCHAI
It is suitable for BOSCH common rail pump engine.
Table 42 – Engine 42 Pins Port
Terminals of controller
Engine 42 pins port
Remark
Programmable output1
1.40
Set configurable output 1 as “Fuel Relay
Output”.
Connect to engine ignition lock.
Start relay output
-
Connect to starter coil directly
-
CAN communication shielding line
CAN(H)
1.35
Using impedance 120Ω connecting line
CAN(L)
1.34
Using impedance 120Ω connecting line
Table 43 – Engine 2 Pins Port
Battery
Engine 2 pins
Remark
Battery negative
1
Wire diameter 2.5mm
2
Battery positive
2
Wire diameter 2.5mm
2
Engine type: BOSCH
