When engine type is GTSC1 PLUS, J1939
message is sent at idle speed, rated speed
and ECU address
Note1: if select high temperature inhibit, or set programmable input as High Temperature Inhibit
(this input is active), when temperature is higher than pre-set threshold, controller sends warning signal
only and not shutdown.
Note2: if select low oil pressure inhibit, or set programmable input as Low Oil Pressure Inhibit (this
input is active), when low oil pressure is lower than pre-set threshold, controller sends warning signal
only and not shutdown.
Note3: If default password (0318) isn’t changed, it doesn’t need to input when configuring
parameters via PC software; if the password is changed for the first time via PC software, it needs to
input password in password window.
Note4: Between input correct password and LCD back light haven’t got dark, input parameter
numbers can enter parameter setting interface when enters “Password Input” again.
Note5: In teeth configuration interface, if being in teeth configuration status and frequency is larger
than 20Hz, press start key for auto calculating teeth numbers and press confirm key for changing teeth
numbers.
7.2 PROGRAMMABLE OUTPUT 1-4 TABLE
Table 12 – Definition Content of Programmable Output 1-4
Including all shutdown alarm and warning alarm. When a warning
alarm occurs, the alarm won’t self-lock; When a shutdown alarm
occurs, the alarm will self-lock until alarm is reset.
