HGMS61 Genset Controller User Manual Page 27 of 47
No.
Items
Description
2
Energize to Stop
Used for the genset with stop solenoid. Pick-up when idle speed is
over while disconnect when ETS delay is over.
3
Idle Control
Used for the genset with idle speed. Pick-up when crank while
disconnect when enter into warming up. Pick-up when stop idle
while disconnect when genset stop completely.
4
Preheat Control
Close before starting and disconnect before power-on.
5
Close Gen Output
When close time is set as 0, it is continuous closing.
6
Reserved
7
Open
When close time is set as 0, Open Breaker is disabled.
8
Speed Rise Control
Pick-up when enter into warming up time. The pick-up time is
warming up delay.
9
Speed Drop Control
Pick-up when enter into stop idle or ETS solenoid stop (shutdown
alarm). The pick-up time is stop idle delay.
10
Run Output
Output when genset is in normal running, disconnect when
rotating speed is lower than engine speed after fired.
11
Fuel Pump Control
Pick-up when the fuel level lower than the open threshold or low
fuel level warning is active; disconnect when the fuel level over the
close threshold and the low fuel level warning input is disabled.
12
High Speed Control
Output when it enters into warming up time, and disconnect after
cooling.
13
Auto Mode
The controller is in Auto Mode.
14
Shutdown Alarm
Output when shutdown alarm occurs.
15
Audible Alarm
When shutdown alarm and warn alarm, audible alarm is set as
300s. In audible alarm output duration, when press any key or
“alarm mute” input is active, it can remove the alarm.
16
Coolant Heating Control
It is controlled by heating of temperature sensor’s limited
threshold.
17
Fuel On
Action when genset is starting and disconnect when stop is
completed.
18
Start Output
Genset output in start output status and open in other status.
19
ECU Stop
Used for ECU engine and control its stop.
20
ECU Power Supply
Used for ECU engine and control its power.
21
ECU Warning
Indicate ECU sends a warning signal.
22
ECU Shutdown
Indicate ECU sends a shutdown signal.
23
ECU Communication Failure
Indicate controller cannot communicate with ECU.
24
Speed Raise Pulse
Raising speed time is output while the unit entering into hi-speed
warming up.
25
Speed Drop Pulse
Dropping speed time is output while the unit entering into stop
idling.
