HGMS61 Genset Controller User Manual Page 42 of 47
13.9 DEUTZ EMR2
Table 30 – F Connector
Terminals of controller
F connector
Remark
Programmable output1
Expand 30A relay, battery
voltage of 14 is supplied
by relay. Fuse is 16A
Set configurable output 1 as “Fuel Relay
Output”.
Start relay output
-
Connect to starter coil directly
-
1
Connect to battery negative pole
-
CAN communication shielding line
CAN(H)
12
Using impedance 120Ω connecting line
CAN(L)
13
Using impedance 120Ω connecting line
Engine type: VOLVO- EDC4
13.10 JOHN DEERE
Table 31 – 21 Pins Connector
Terminals of controller
21 pins connector
Remark
Programmable output1
G,J
Set configurable output 1 as “Fuel Relay
Output”.
Start relay output
D
-
CAN communication shielding line
CAN(H)
V
Using impedance 120Ω connecting line
CAN(L)
U
Using impedance 120Ω connecting line
Engine type: JOHN DEERE
13.11 MTU ADEC(SMART MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 32 – ADEC (X1 port)
Terminals of controller
ADEC (X1port)
Remark
Programmable output1
X1 10
Set configurable output 1 as “Fuel Relay
Output”.
X1 Terminal 9 Connected to negative of
battery
Start relay output
X1 34
X1 Terminal 33 Connected to negative of
battery
Table 33 - SMART (X4 port)
Terminals of controller
SMART (X4 port)
Remark
X4 3
CAN communication shielding line
CAN(H)
X4 1
Using impedance 120Ω connecting line
CAN(L)
X4 2
Using impedance 120Ω connecting line
Engine type: MTU-ADEC
