HGMS61 Genset Controller User Manual Page 25 of 47
No.
Items
Range
Default
Description
73
Over Power Action
(0~2)
0
0 Not used; 1 Warn; 2 Shutdown
When power is higher than preset value and
duration exceeds than delay, over power
warning is active. Return and delay value
can be set.
74
Start Interface
(0~1)
0
0:Disable; 1:Enable.
Start interface delay can be set.
75
Maintenance
Password
(0~9999)
0
Enter password interface of maintenance
configuration.
76
Date/Time
Set the date/time of controller.
77
Flexible Sensor Curve
Type
(0~2)
0
0 User-defined temperature sensor
1 User-defined pressure sensor
2 User-defined level sensor
Choose sensor which needs to be set, input
every point (8 points need to be input)
resistance and corresponding value(or
current, voltage) of curve.
78
Engine Type
(0~39)
0
0: Conventional Genset
79
SPN Alarm Version
(0~3)
0
SPN Alarm Version
80
Custom Theme
(0~2)
0
0:Default Theme; 1:OEM Plant Theme;
2: Terminal Users Theme
81
Fuel Output Time
(1~60)s
1
It is the time of the genset fuel output during
power on.
82
Manual Mode ATS
(0~1)
0
0: Key Switch; 1: Auto Switch.
83
Speed Raise Pulse
(0~20.0)s
0.2
It is the speed-up pulse output time, when
the unit enters the high-speed warming up.
84
Speed Drop Pulse
(0~20.0)s
0.2
It is the speed-drop pulse output time, when
the unit enters the stop idling.
85
Fuel Level Low
Shutdown
(0~100)%
5
When fuel level of external level sensor falls
below the setting limit and lasts for 5s, low
fuel shutdown alarm will be initiated; if limit
value set as 0, low fuel shutdown alarm will
not be initiated.
86
ATS Open Time
(1.0~60.0)s
3.0
87
Gen PT Ratio
(0~1)
0
0:Disable; 1:Enable. PT primary and PT
secondary can be set.
88
Mains Options
(0~1)
0
0:AMF; 1:Disable.
89
Active Power
Loading Percentage
(0~1)
0
0:Disabled 1:Enable. When it is enabled, it is
active power/rated power*100; when it is
disabled, it is average current of the
3-phase/rated current*100;
90
Charger Voltage
Sampling Options
(0~1)
0
0: Controller; 1: ECU
