Smartgen HGMS61 User Manual

HGMS61 Genset Controller User Manual Page 24 of 47
No.
Items
Range
Default
Description
55
Crank Disconnect
Condition
(0~6)
2
Conditions of disconnecting starter
(generator, magnetic pickup sensor, oil
pressure), aiming to separate the start
motor and genset as soon as possible.
56
Engine Speed of
Crank Disconnect
(0~3000)r/min
360
When engine speed is over this value, starter
will disconnect.
57
Frequency of Crank
Disconnect
(0.0-30.0)Hz
14.0
When generator frequency is over this point,
starter will disconnect.
58
Oil Pressure of Crank
Disconnect
(0~400)kPa
200
When engine oil pressure is over this value,
starter will disconnect.
59
High Temp. Stop
Inhibit
(0~1)
0
Default: when temperature is too high, the
genset will alarm and shutdown.
60
Low OP Inhibit Stop
Inhibit
(0~1)
0
Default: when oil pressure is too low, it will
alarm and shutdown.
61
AC System
(0~3)
0
0: 3P4W 1: 2P3W
2: 1P2W 3: 3P3W
62
Temp. Sensor
Curve Type
(0~14)
8
SGX See Table 14
63
Pressure Sensor
Curve Type
(0~14)
8
SGX See Table 14
64
Fuel Level Sensor
Curve Type
(0~7)
3
SGD See Table 14
65
Generator Poles
(2~64)
4
Number of magnetic poles, used for
calculating rotating speed of generator
without speed sensor.
66
Temp. Sensor Open
Circuit Action
(0~2)
1
0: Not used; 1: Warning;
2: Shutdown
67
Oil Pressure Sensor
Open Circuit Action
(0~2)
1
68
Disconnect Oil
Pressure Delay
(0~20.0)s
0.0
When disconnect conditions include oil
pressure and engine oil pressure is higher
than disconnect oil pressure delay, the
genset is regarded as start successfully and
starter will disconnect.
69
Scheduled Run
(0~1)
0
0:Disable; 1:Enable.
70
Scheduled Period
(0~1)
0
Circulate condition: monthly, weekly and
daily can be selected.
Start time and duration can be set.
71
Auto Start Inhibited
(0~1)
0
0:Disable; 1:Enable.
72
Scheduled Period
(0~2)
0
Circulate condition: monthly, weekly and
daily can be selected.
Won’t start time and duration can be set.
