HGMS61 Genset Controller User Manual Page 23 of 47
No.
Items
Range
Default
Description
29
Battery Under
Voltage
(4.0~30.0)V
8.0
When battery voltage is under the value and
remains for 20s, battery under voltage signal
is active. it only warn but not shutdown.
30
CT Ratio
(5~6000)/5
500
Current transformer ratio.
31
Full Load Rating
(5~6000)A
500
Rated current of generator, used for
calculating over load current.
32
Over Current
Percentage
(50~130)%
120
When load current is over the value, the over
current delay is initiated.
33
Over Current Delay
(0~3600)s
30
When load current is over the value, over
current signal is sent. When the delay is 0,
only warn but not shutdown.
34
Fuel Pump On
(0~100)%
25
When the fuel level lower than the set value
for 2s, it will send a signal to open fuel
pump.
35
Fuel Pump Off
(0~100)%
80
When the fuel level higher than the set value
for 2s, it will send a signal to close fuel
pump.
36
Relay Output 1
(0~28)
2
Factory default: Energized to stop. See Table
12.
37
Relay Output 2
(0~28)
3
Factory default: Idle control. See Table 12.
38
Relay Output 3
(0~28)
5
Factory default: Gens closed. See Table 12.
39
Relay Output 4
(0~28)
6
Factory default: Reserved. See Table 12.
40
Digital Input 1 Set
(0~23)
1
Factory default: High temperature alarm
input. See Table 13.
41
Digital Input 1 Active
(0~1)
0
Factory default: close
42
Digital Input 1 Delay
(0~20.0)s
2.0
43
Digital Input 2 Set
(0~23)
2
Factory default: Low oil pressure alarm
input. See Table 13.
44
Digital Input 2 Active
(0~1)
0
Factory default: close
45
Digital Input 2 Delay
(0~20.0)s
2.0
46
Digital Input 3 Set
(0~23)
10
Factory default: Remote start input. See
Table 13.
47
Digital Input 3 Active
(0~1)
0
Factory default: close
48
Digital Input 3 Delay
(0~20.0)s
2.0
49
Digital Input 4 Set
(0~23)
11
Factory default: Low fuel level warn input.
See Table13.
50
Digital Input 4 Active
(0~1)
0
Factory default: close
51
Digital Input 4 Delay
(0~20.0)s
2.0
52
Power On Mode
(0~2)
0
0: Stop Mode; 1: Manual Mode; 2: Auto
Mode
53
Module Address
(1~254)
1
The communication address of controller.
54
Password
(0~9999)
0318
Module password.
