HGMS61 Genset Controller User Manual Page 22 of 47
When the engine speed is under the value
for 10s, shutdown alarm signal is sent out.
When the engine speed is over the point for
2s, shutdown alarm signal is sent.
Gen Under Frequency
Shutdown
When generator frequency is lower than the
value (not equal to 0) for 10s, shutdown
alarm signal is sent.
Gen Over Frequency
Shutdown
When generator’s frequency is over the
value and continues for 2s, shutdown alarm
signal is sent.
When engine temperature sensor value is
over this value, it sends out high temp.
alarm. This value only be judged after the
end of safety delay, and only for the
temperature sensor connected outside.
When the value is 300, warning alarm won’t
be sent. (only suites for temperature sensor,
except for high temp. pressure alarm signal
inputted by programmable input port )
Low Oil Pressure
Shutdown
When engine oil pressure sensor value is
under this value, Low Oil Pressure alarm is
sending out. This value only judged after the
end of safety delay. When the value is 0,
warning alarm won’t be sent. (only suites for
oil pressure sensor, except for low oil
pressure alarm signal inputted by
programmable input port)
Low Fuel Level
Warning Value
When fuel level sensor value under this
value and remains for 10s, genset will send
out warning alarm, only warn but not
shutdown.
Loss Of Speed Signal
Delay
When the delay setting as 0s, it only warn
but not shutdown.
During genset normal running, when B+ and
charger D+ (WL) voltage difference is above
this value for 5s, the controller will issue
Failed To Charge warning.
When battery voltage is over the value and
remains for 20s, battery over voltage signal
is active. it only warn but not shutdown.
To Next Page
