Smartgen HGMS61 User Manual

HGMS61 Genset Controller User Manual Page 9 of 47
Items
Contents
CAN
Isolated, maximum communication length 250m, using Belden
9841 wire or equivalent
CE-EMC Certification
EN 55032, EN 55024
Vibration
5Hz~8Hz：displacement ±7.5mm
8Hz~500Hz：a ±2g
IEC 60068-2-6
Shock
50g, 11ms, half-sine, three successive shocks are applied from
each of the three perpendicular directions, a total of 18 times
IEC 60068-2-27
Bump Test
25g, 16ms, half-sine
IEC 60255-21-2
Production Compliance
According to EN 61010-1 installation category (over voltage
category) III, 300V, pollution class 2, altitude 3000m
Overall Dimensions
HGMS61D：209mm x 167mm x 45mm (Panel Installation)
HGMS61M：248mm x 158mm x 64mm (Cabinet Installation)
Panel Cutout
HGMS61D: 186mm x 141mm
Working Condition
Temperature: (-25~70)ºC; Relative Humidity: (20~93)%RH
Storage Condition
Temperature: (-30~+80)ºC
Protection Level
HGMS61 D: IP65
HGMS61M: IP20
Insulation Intensity
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal. The leakage current is not more than 3mA
within 1min.
Standard
GB/T 37089 Reciprocating internal combustion engine driven
alternating current generating sets—Controller
Weight
HGMS61D: 0.5kg
HGMS61M: 0.8kg

Smartgen HGMS61 Specifications

General

Brand	Smartgen
Model	HGMS61
Category	Controller
Language	English
