Smartgen HMC6 User Manual

HMC6 Power Management Controller User Manual Page 28 of 87
Terminal description：NO means normally open; NC means normally close.
9.2.1 SLOT #1 POWER SUPPLY AND RELAY OUTPUT PORT
Table 11 – Slot#1 Power Supply & Relay Output Port
Terminal
Function
Description
Remarks
1
B-
DC(8~35)V
Power supply input
2
B+
3
AUX.OUTPUT1
Auxiliary output port 1
AC250V/8 A
4
AUX.OUTPUT2
Auxiliary output port 2
AC250V/8 A
5
AUX.OUTPUT3
Auxiliary output port 3
AC250V/8 A
6
COM1
COM port 3~5
NOTE: In case of using battery as power source, make the controller connect to the battery directly instead of start battery
or charging generator to ensure stable supply of HMC6.
9.2.2 SLOT #2, SLOT #3 RELAY OUTPUT PORT
Table 12 – Slot#2, Slot#3 Relay Output Port
Terminal
Function
Description
Remarks
7
RAISE SPEED
Raise speed output
AC250V/8 A
8
COM2
COM port 7,9
9
DROP SPEED
Drop speed output
AC250V/8 A
10
AUX. OUTPUT 7
Default: Raise volt output
AC250V/8 A
11
COM3
COM port 10,12
12
AUX. OUTPUT 8
Default: Drop volt output
AC250V/8 A
13
ENGINE START
Engine start
AC250V/8 A
14
COM4
COM port 13, 15
15
ENGINE STOP
Engine stop
AC250V/8 A
16
GB CLOSE_NC
GB CLOSE output
AC250V/8 A
17
GB CLOSE _COM
18
GB CLOSE _NO
19
GB OPEN _NC
GB OPEN output
AC250V/8 A
20
GB OPEN _COM
21
GB OPEN _NO
22
AUX. OUTPUT 9
Default: Audible alarm output
AC250V/8 A
23
