Smartgen HMC6 User Manual

HMC6 Power Management Controller User Manual Page 54 of 87
11.4 GENERATOR LOAD SETTING
Table 22 – Generator Load Settings
No.
Items
Parameter Range
Default
Description
Load
1.
CT Ratio
(5-6000)/5
500/5
The ratio of external CT.
2.
Full Load Rating
(5-6000)A
500
Generator’s rated current.
3.
Rated Active Power
(5-20000)kW
276
Generator’s rated active power.
4.
Rated Reactive Power
(5-20000)kvar
210
Generator’s rated reactive power.
5.
Overload To Ask 1
(0-2000)kW
100
The request active power of busbar
overload.
6.
Overload Rated 1
(0-2000)kW
60
The rated active power of busbar
overload.
7.
Overload To Ask 2
(0-2000)kW
100
The request active power of busbar
overload.
8.
Overload Rated 2
(0-2000)kW
60
The rated active power of busbar
overload.
9.
Overload To Ask 3
(0-2000)kW
100
The request active power of busbar
overload.
10.
Overload Rated 3
(0-2000)kW
60
The rated active power of busbar
overload.
11.
Over Current
1 Set
Action
(0-1)
0:Diable
1:Enable
1:Enable
12.
Set Value
(50-300)%
100
13.
Delay
(0.1-999.9)s
20.0
14.
Alarm Type
(0-5)
1:Warn
15.
Over Current
2 Set
Action
(0-1)
0:Diable
1:Enable
1:Enable
16.
Set Value
(50-300)%
110
17.
Delay
(0.1-999.9)s
60.0
18.
Alarm Type
(0-5)
2:Trip
19.
Over Current
3 Set
Action
(0-1)
0:Diable
1:Enable
1:Enable
20.
Set Value
(50-300)%
130
21.
Delay
(0.1-999.9)s
30.0
22.
Alarm Type
(0-5)
2:Trip
23.
Over Current
4 Set
Action
(0-1)
0:Diable
1:Enable
1:Enable
