HMC6 Power Management Controller User Manual Page 34 of 87
9.3.6 MSC LINK PORT
Data sharing and data communication functions among HMC6 controllers are implemented via MSC LINK
(CANBUS port). Detailed connection way is as following:
Fig.10 – HMC6 Module Communication Connection Diagram
9.3.7 MSC APPLICATION DIAGRAM
Fig.11 – MSC Application Diagram
