HMC6 Power Management Controller User Manual Page 72 of 87
No.
Name
Description
Remark
137
DIN16-1 IN6 Active
138
DIN16-1 IN7 Active
139
DIN16-1 IN8 Active
140
DIN16-1 IN9 Active
141
DIN16-1 IN10 Active
142
DIN16-1 IN11 Active
143
DIN16-1 IN12 Active
144
DIN16-1 IN13 Active
145
DIN16-1 IN14 Active
146
DIN16-1 IN15 Active
147
DIN16-1 IN16 Active
148
Grid Connection Overtime Of
SG & DG
Output when the grid connection time of SG and DG is
over the set value.
149
Parallel Number Excessive Of
SG & DG
when SG and DG are grid-connected running, output
when the number of DG is over the set value.
150
Overload To Permit 4
When overload 4 requests, output when the unit power
meets the requirement, otherwise, it will not output.
11.9 SYNCHRONIZATION SETTING
Table 30 – Synchronization Settings
No.
Items
Parameter Range
Default
Description
Synchronization Setting(Basic)
1
Governor Output
(0-2)
1
0: Internal relay; 1: Internal analog; 2: None.
2
GOV Reverse Output
Enable
(0-1)
0
0: Disable; 1: Enable.
3
GOV Loading Action
(0-2)
1
0: None; 1: Adjust raged frequency; 2: Adjust
center point.
4
Voltage Regulator
Output
(0-2)
1
0: Internal relay; 1: Internal analog; 2:None.
5
AVR Reverse Output
Enable
(0-1)
0
0: Disable; 1: Enable.
6
AVR Loading Action
(0-2)
1
0: None; 1: Adjust raged voltage; 2: Adjust center
point.
7
Load Ramp Rate
(0.1-100.0)%/s
3.0
Speed of genset ramp on/off load per second.
8
Load Ramp Rate
Delay Percent
(0.1-40.0)%
10.0
Ladder point of genset ramp on/off load.
9
Load Ramp Rate
Delay Value
(0-30)s
0
Delay time of per ladder point of genset ramp
on/off load.
10
Multi-unit
Communication
Amount
(1-16)
2
The unit number of MSC bus.
