HMC6 Power Management Controller User Manual Page 71 of 87
No.
Name
Description
Remark
109.
HC 1 Allowed
When HC requests, and genset power is met, this
outputs; when power is not met, it doesn't output.
110.
HC 2 Allowed
111.
HC 3 Allowed
112.
Unbalanced Distribution of
Active Power
113.
Unbalanced Distribution of
Reactive Power
114.
Unbalanced Distribution of
Load
Outputs when either active distribution unbalanced
or reactive distribution unbalanced is effective.
115.
Self-check Normal Output
116.
Close Input Port Active
Outputs when closing input port is effective.
117.
Manual Mode Input Active
Outputs when manual mode input port is effective.
118
Reserved
119
Reserved
120
Reserved
121
SG Solenoid Valve Closing
SG solenoid valve closes and outputs.
122
SG Solenoid Valve Opening
SG solenoid valve opens and outputs.
123
SG Capacity Insufficient
When the controller operates in SG mode and load
receiving mode, if SG on-load is effective, but SG
outputs when capacity is insufficient to receive the full
load.
124
DG Capacity Insufficient
When the controller operates in SG mode and load
receiving mode, if DG on-load is effective, but SG
outputs when capacity is insufficient to receive the full
load.
125
SG & DG Parallel No. Exceeds
Limit
When SG and DG are on-grid at the same time or to
synchronize, the DG switch number exceeds the set
value and outputs.
126
Busbar Freq. Change
Abnormal
Output when the bus frequency change rate exceeds
the set value and the delay value.
127
Gen. Freq. Change Abnormal
Generating frequency change rate exceeds the set
value and the delay value.
128
Blackout
The controller outputs when it detects that the whole
ship is black out.
129
NEL 1 Pre-tripping
When controller detects that NEL condition is active
and outputs while the delay is not due.
130
NEL 2 Pre-tripping
131
NEL 3 Pre-tripping
132
DIN16-1 IN1 Active
Outputs when DIN16-1 module input is active.
133
DIN16-1 IN2 Active
134
DIN16-1 IN3 Active
135
DIN16-1 IN4 Active
136
DIN16-1 IN5 Active
