Smartgen HMC6

HMC6 Power Management Controller User Manual Page 70 of 87
No.
Name
Description
Remark
75.
Start Success
Active when the generator voltage and frequency have
reached the requirement.
76.
Synchronizing
77.
Common Safety Trip
78.
Common Safety Stop
79.
Overload To Answer 4
Output when meets the start power of Overload 3.
80.
Remote Control Output
The opening and closing of this output port can be
controlled by PC software or ModBus protocol.
81.
PLC Flag 1
82.
PLC Flag 2
83.
PLC Flag 3
84.
PLC Flag 4
85.
PLC Flag 5
86.
PLC Flag 6
87.
PLC Flag 7
88.
PLC Flag 8
89.
PLC Flag 9
90.
PLC Flag 10
91.
PLC Flag 11
92.
PLC Flag 12
93.
PLC Flag 13
94.
PLC Flag 14
95.
PLC Flag 15
96.
PLC Flag 16
97.
PLC Flag 17
98.
PLC Flag 18
99.
PLC Flag 19
100.
PLC Flag 20
101.
Busbar Voltage Abnormal
102.
Busbar Frequency Abnormal
103.
Busbar Voltage Frequency
Abnormal
104.
Lamp Alarm
When common alarm occurs, it outputs cyclically
every 0.5 second; it keeps outputting after
acknowledge.
105.
Audible Alarm
Output at common alarms, close to output after
acknowledge.
106.
Failed to Unload
107.
Unload Output
108.
Gen Capacity Insufficient
When controller detects all normal gensets are online,
and remaining power cannot request power, this
outputs.
