HMC6 Power Management Controller User Manual Page 29 of 87
9.2.3 SLOT #4 CANBUS PORT, GOV ANALOG PORT AND AVR ANALOG PORT
Table 13 – Slot#4 CANBUS Port, GOV Analog Port and AVR Analog Port
Terminal
Function
Description
Remarks
24
SCR
(MSC LINK)
CANBUS COM port
Multi-sets communication MSC LINK
port
Used for data sharing between HMC6
controllers.
25
CANH
(MSC LINK)
26
CANL
(MSC LINK)
27
SCR
(EXPANSION)
CANBUS COM port
Expand CANBUS port
Used for data sharing between HMC6
controllers. Used for expand digital input
module, digital output module or LED
lamp module.
28
CANH
(EXPANSION)
29
CANL
(EXPANSION)
30
mA
(GOV/AOUT1)
Output -20mA ~20mA
GOV Output can output simultaneously
-20mA~20mA and -10V~10V;
Can be transducer AOUT1 output;
31
VDC
Output -10V~10V
32
COM5
GOV COM Output
33
mA
(AVR/AOUT2)
Output -20mA ~20mA
AVR Output can output simultaneously
-20mA~20mA and -10V~10V;
Can be transducer AOUT2 output;
34
VDC
Output -10V~10V
35
COM6
AVR COM Output
9.2.4 SLOT #5, SLOT #6, SLOT #7 GENERATOR VOLTAGE INPUT/BUSBAR VOLTAGE
INPUT/GENERATOR CURRENT INPUT PORT
Table 14 – Slot#5, Slot#6, Slot#7 Gen/Busbar Voltage, Gen Current Input Ports
Terminal
Function
Description
Remarks
36
L1 (GENSET)
Genset A-phase voltage sensing input
Maximum input 360V
37
L2 (GENSET)
Genset B-phase voltage sensing input
Maximum input 360V
38
L3 (GENSET)
Genset C-phase voltage sensing input
Maximum input 360V
39
N (GENSET)
Genset N-phase voltage sensing input
40
L1 (BUS)
Busbar A-phase voltage sensing input
Maximum input 360V
41
L2 (BUS)
Busbar B-phase voltage sensing input
Maximum input 360V
42
L3 (BUS)
Busbar C-phase voltage sensing input
Maximum input 360V
43
N (BUS)
Busbar N-phase voltage sensing input
44
S1 (CT1)
Gen A-phase sensing input
Rated input 5A
45
S2 (CT1)
46
S1 (CT2)
Gen B-phase sensing input
Rated input 5A
47
S2 (CT2)
48
S1 (CT3)
Gen C-phase sensing input
Rated input 5A
49
S2 (CT3)
