11.7 INPUT PORTS SETTING
Active type: Low-level; Response time> 500ms
Table 26 – Digital Input Ports Settings
No.
Items
Parameter Range
Default
Description
Digital Input Ports
Fixed Input 1
1.
Contents Setting
Fixed
Fixed
Close input
2.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Aux. Input 9
3.
Contents Setting
(0-99)
49
Engine Run Feedback
4.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Fixed Input 3
5.
Contents Setting
Fixed
Fixed
Manual Mode
6.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Fixed Input 4
7.
Contents Setting
Fixed
Fixed
Engine Fault Input
8.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 1
9.
Contents Setting
(0-99)
0
Not used
10.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 2
11.
Contents Setting
(0-99)
0
Not used
12.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 3
13.
Contents Setting
(0-99)
0
Not used
14.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 4
15.
Contents Setting
(0-99)
0
Not used
16.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 5
17.
Contents Setting
(0-99)
0
Not used
18.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 6
19.
Contents Setting
(0-99)
0
Not used
20.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 7 (Multiplexing with frequency modulation FREQ IN+)
21.
Contents Setting
(0-99)
0
Not used
22.
Active Type
(0-1)
0
0: Close activate 1: Open activate
Programmable Input 8 (Multiplexing with voltage modulation VOLT IN+)
23.
Contents Setting
(0-99)
0
Not used
24.
Active Type
(0-1)
0
0: Close activate 1: Open activate
