Table 25 – Transducer Configuration Function List
No.
Item
Description
0.
Not Used
Transducer function is not used.
1.
Busbar Voltage
2.
Busbar Frequency
3.
Busbar Active Power
4.
Busbar Inactive Power
5.
Busbar Apparent Power
6.
Reserved
7.
Gen Voltage
8.
Gen Frequency
9.
Gen Active Power
10.
Gen Inactive Power
11.
Gen Apparent Power
12.
Gen Power Factor
13.
Gen Phase-A Current
14.
Gen Phase-B Current
15.
Gen Phase-C Current
16.
Gen Max. Current
17.
Busbar Surplus Power
18.
Unit Surplus Power
19.
Reserved
20.
Reserved
