Smartgen HMC6 User Manual

HMC6 Power Management Controller User Manual Page 8 of 87
3.5 POWER MANAGEMENT FUNCTIONS
Plant operation:
● Diesel generator supply (up to 16 generators)
● Shore power supply (all gensets are inhibit to start and take on load)
Power management functions:
● Blackout handling
●Load-dependent start/stop
●Auto start mode selection
► Cyclic start
► Linear start
► Duty time start
●Auto scheduled start mode selection
► Genset power percentage
► Left power
● Priority Trip
● Heavy consumer
● Light consumer
● Reserved number of running gensets
● Safety stop, safety trip
●Safety mode (reserve an additional unit running on load)
●Limit network-connected gensets numbers
●Busbar breaking handle
4. SPECIFICATION
Table 3 – Specification Parameters
Parameter
Content
Working Voltage
DC8. 0V to 35. 0V, continuous power supply
Overall Consumption
<4W (Standby mode: ≤2W)
AC Input:
3 Phase 4 Wire
3 Phase 3 Wire
2 Phase 3 Wire
Single Phase
AC15V - AC360V (ph-N)
AC30V - AC620V (ph-ph)
AC15V - AC360V (ph-N)
AC15V - AC360V (ph-N)
Alternator Frequency
50Hz/60Hz
Flexible Relay Output
8A AC250V volts free output
GOV
DC(-10~10)V/(-20~20)mA
AVR
DC(-10~10)V /(-20~20)mA
FREQ IN
DC(-10~10)V
VOLT IN
DC(-10~10)V
Case Dimensions
266mm x 182mm x 45mm
Panel Cutout
214mm x 160mm
CT Secondary Current
Rated 5A

Smartgen HMC6 Specifications

General

Brand	Smartgen
Model	HMC6
Category	Controller
Language	English
