HMC6 Power Management Controller User Manual Page 51 of 87
No.
Items
Parameter Range
Default
Description
disconnect frequency is satisfied or
not.
8
Volt.
Trans.(PT)
Action
(0-1)
0: Disable
1 :Enable
0:Disable
Primary/secondary voltage of voltage
transformer can be set.
9
PT Primary
(30-30000)V
100
10
PT
Secondary
(30-1000)V
100
11
Over Voltage
1 Set
Action
(0-1)
0: Disable
1: Enable
1:Enable
Setting value is percentage of
generator rated voltage. Delay value
and return value can be set.
12
Set value
(80-120)%
105
13
Delay
(0.1-100.0)s
5.0
14
Alarm
Type
(0-5)
0: Block
1: Warn
2: Trip
3: Shutdown
4: Safety Trip
5: Safety Stop
1: Warn
15
Over Voltage
2 Set
Action
(0-1)
0: Disable
1: Enable
1:Enable
16
Set value
(80-120)%
115
17
Delay
(0.1-100.0)s
1.0
18
Alarm
Type
(0-5)
2:Trip
19
Under
Voltage 1 Set
Action
(0-1)
0: Disable
1: Enable
1:Enable
20
Set value
(50-100)%
95
21
Delay
(0.1-100.0)s
5.0
22
Alarm
Type
(0-5)
1:Warn
23
Under
Voltage 2 Set
Action
(0-1)
0: Disable
1: Enable
1:Enable
24
Set value
(50-100)%
80
25
Delay
(0.1-100.0)s
3.0
26
Alarm
Type
(0-5)
2:Trip
27
Under
Action
(0-1)
0:Disable
