HMC6 Power Management Controller User Manual Page 63 of 87
No.
Name
Description
Auto
Mode
Semi-auto
Mode
Manual
Mode
Acknowledge signal is initiated if the requirements
are satisfied. If not satisfied, standby gensets will
be started to meet with the requirement.
11.
HC 3 Feedback
After breaker closing, feedback signal is send to
controller to ensure the HC3 has loaded.
●
●
Х
12.
Engine Fault
Engine fault feedback input.
●
●
Х
13.
Alarm Inhibit
All alarms are inhibited after input is active.
●
●
●
14.
Alarm Mute
Mute the panel buzzer.
●
●
●
15.
Alarm Reset
Reset alarms.
●
●
●
16.
Alarm Ack
Acknowledge the current alarm.
●
●
●
17.
Lamp Test
Test all the LED lights.
●
●
●
18.
Light Load
The controller doesn’t open breaker even if the
system load has fallen below the set value.
●
●
Х
19.
Constant Power
IN
Fixed power output, when the “Constant Power
input” is active, the active power and the reactive
power can be adjusted via fixed power setting
parameter, or when the external adjust input is
active, the active power and the reactive power can
be adjusted via external FREQ IN port and VOLT IN
port.
●
●
Х
20.
Cycle Start
Cycle start mode is carried out when the input is
active.
●
Х
Х
21.
Linear Start
Linear start mode is carried out when the input is
active.
●
Х
Х
22.
Duty Time Start
Duty time start mode is carried out when the input is
active.
●
Х
Х
23.
Auto Mode Input
Auto mode is carried out when the input is active.
●
●
●
24.
Semi Auto Mode
Semi auto mode is carried out when the input is
active.
●
●
●
25.
Remote Closing
Synchronization and closing process will be carried
out when the input is active.
Х
●
Х
26.
Remote Opening
Opening process will be carried out when the input
is active.
Х
●
Х
27.
Remote Start
The genset will be started and synchronized
automatically when the input is active.
Х
●
Х
28.
Remote Stop
The genset will be stopped after unload when the
input is active.
Х
●
Х
29.
Safe Mode
An additional genset will be started even if the
power request is satisfied when the input is active.
●
Х
Х
30.
Ready OK
The signal output when the preparation work is
done. If the function is selected, the engine will be
●
●
Х
