IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
3.7.1 SURFACE MOTION SENSOR CABLE CONNECTION
IMU Connector
Cable Colour
IMU Function
External device
A
White
RS232 RxD main
DB9 pin3 TxD
B
Red
RS232 TxD main
DB9 pin2 RxD
C
Brown
RS422 TxD+ main
DB9 pin3 RxD+
D
Orange
RS422 TxD- main
DB9 pin4 RxD-
E
Green
RS422 RxD- main
DB9 pin1 TxD-
F
Purple
RS422 RxD+ main
DB9 pin2 TxD+
G
Yellow
RS232 TxD serial aiding/input
DB9 pin2 RxD
H
Transparent
RS232 RxD serial aiding/input
DB9 pin3 TxD
J
Black
RS232 TxD serial aiding/input
DB9 pin2 RxD
K
Blue
RS232 RxD serial aiding/input
DB9 pin3 TxD
L
Grey
Supply Voltage -
M
Pink
Supply Voltage + 12 to 30Vdc
S
White/Black
Ethernet TxD+
RJ45 pin1 RxD+
T
White/Red
Ethernet TxD-
RJ45 pin2 RxD-
U
White/Green
Ethernet RxD+
RJ45 pin3 TxD+
V
White/Yellow
Ethernet RxD-
RJ45 pin6 TxD-
Position A to V is available on motion sensor with hardware 8.5 or higher. On the 12-wire cable
position A to M is available only. The 12-wire cable and connector and 19-wire cables are inter-
changeable for the serial communication.
