SMC Networks IMU-108 User Manual

77
IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
4.5.5 WINDOWS FIREWALL
Normally the Windows Firewall rules for the SMC IMU Configuration software are created on first
launch of the software.
However, if the configuration software does not display all the values for Target IP etc. in the IP and
Port settings section it is usually due to a firewall rule setting.
The host PC and any client PCs should have an Inbound Rule for UDP and TCP as shown below
The default path to the SMC IMU configuration software executable is
C:\Program Files (x86)\Ship Motion Control\SMC IMU Configuration Software\SMCconfiguration.exe
If a problem occurs, close the configuration software and delete all SMC IMU Configuration Firewall
rules, relaunch the software and accept the automatically created rules.

SMC Networks IMU-108 Specifications

General

Brand	SMC Networks
Model	IMU-108
Category	Accessories
Language	English
