IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
4.4.7 ANALOG7 4~20MA, HEAVE ±5M, HEAVE RATE ±5M/S, HEAVE ACC 5M/S2
Data Frame
#01C0+00.370<CR><LF>
#01C1+00.171<CR><LF>
#01C2+01.144<CR><LF>
Description
Form
Analog Channel 0
Heave 4~10mA = ±5m
Analog Channel 1
Heave Rate 4~10mA = ±5m/s
Analog Channel 2
Heave Acceleration 4~10mA = ±5m/s
2
