IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
4.2.18 DD50
The DD50 string is intended to be used to connect the Vaisala DD50 LED display.
Example
DDA@1 "IMU / MRU",Units,Roll 02.78 deg,Pitc -02.09 deg,Heav 00.00 m,@2 "Accs ",Units,AccX -
00.00 ms2,AccY 00.00 ms2,AccZ 00.00 ms2
Note: In firmware versions 3.22 and lower this output alternates with the SMCC protocol.
In firmware version 3.22 and lower
Bitrate
Max output Rate
115200
46
57600
23
38400
15
19200
7
9600
3
4800
1
In firmware version 3.24 and higher
Bitrate
Max output Rate
115200
79
57600
39
38400
26
19200
13
9600
6
4800
3
Data displayed on the DD50 is Roll, Pitch and Heave on the first page. Acceleration X, Y and Z on the
second page.
