SMC Networks IMU-108 User Manual

27
IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
3.7.2 DEPTH RATED UNIT
RS232 Output Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
1
Black
RS232 – RxD
3
2
White
RS232 – TxD
2
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12 to 30Vdc
RS422 Output Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
3
Red
RS422 – TxD+
3
4
Green
RS422 – TxD-
4
5
Orange
RS422 – RxD-
1
6
Blue
RS422 – RxD+
2
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12to 30Vdc
RS232 Serial Input 1 Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
7
White/Black
RS232 – TxD
2
8
Red/Black
RS232 – RxD
3
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12 to 30Vdc
RS232 Serial Input 2 Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
9
Green/Black
RS232 – TxD
2
10
Orange/Black
RS232 – RxD
3
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12 to 30Vdc
