1.1 RECEIVING THE MOTION SENSOR
Unpack the equipment and remove all the packaging materials and shipping carton.
The standard motion sensors are delivered in a transit case designed to protect it from high shocks
during transit.
When the motion sensor has been received, it must be inspected for damage during shipment. If
damage has occurred during transit, all the shipping cartons and packaging materials should be
stored for further investigation. If damage is visible, a claim for shipping damage must be filed
immediately.
Because of the sensitive nature of the motion sensor the package must not be dropped.
Standard Delivered Items
• Motion Sensor
• Transit Case
• Junction Box fitted with
o Cable from Motion sensor to JB 10m, 19 core cable
o Serial Output Data cable 1.5m
o AC Input Cable 0.9m
• Calibration Certificate
• CD with IMU Configuration Software and IMU User Manual
