SMC Networks PF3A801H-L User Manual

-85-
No.PF※※-OMY0005
●Product individual parameters (continued)
Index
Sub
index
Access
1
Parameter
Data
type
2
Initial
value
Data
storage
3
Set value
4
Remarks
dec
hex
1430
0x0596
1
R/W
OUT2 setting
(tEMP)
ModE2
(Selection of output
mode)
U8
0
Y
0: HYS (Hysteresis)
1: Wind
(Window comparator)
2
R/W
2ot
(Selection of output
type)
U8
0
Y
0: 1_P (Normal output)
1: 1_n (Reverse output)
Setting of OUT2 output normal and
reserved output
1440
0x05A0
1
R/W
P_2 (n_2)
(Selection of output
set value)
S16
250
Y
Setting range
0xFF9C to 0x0258
(-100 to 600)
Setting of OUT2 output set value
(Hysteresis)
2
R/W
H_2
(Setting of OUT1
hysteresis)
U16
25
Y
Setting range
0x0000 to 0x02BC
(0 to 700)
Setting of OUT2 hysteresis
(Hysteresis)
3
R/W
P2L (n2L)
(Lower limit of window
comparator)
S16
150
Y
Setting range
0xFF9C to 0x0258
(-100 to 600)
Setting of OUT2 output set value
(Lower limit of window comparator)
4
R/W
P2H (n2H)
(Upper limit of window
comparator)
S16
300
Y
Setting range
0xFF9C to 0x0258
(-100 to 600)
Setting of OUT2 output set value
(Upper limit of window comparator)
5
R/W
WH2
(Window comparator
hysteresis)
U16
50
Y
Setting range
0x000 to 0x015E
(0 to 350)
Setting of OUT2 hysteresis
(Window comparator)
6
R/W
dtH2
(Delay time ON)
U16
0
Y
Setting range
0x0000 to 0x1770
(0 to 6000)
Setting of OUT2 delay time ON
10 ms increments
7
R/W
dtL2
(Delay time OFF)
U16
0
Y
Setting of OUT2 delay time OFF
10 ms increments
1450
0x05AA
1
R/W
OUT2 setting
(PrSE)
ModE2
(Selection of output
mode)
U8
0
Y
0: HYS (Hysteresis)
1: Wind
(Window comparator)
2
R/W
2ot
(Selection of output
type)
U8
0
Y
0: 1_P (Normal output)
1: 1_n (Reverse output)
Setting of OUT2 output normal and
reserved output
1460
0x05B4
1
R/W
P_2 (n_2)
(Selection of output
set value)
S16
500
Y
Setting range
0xFFCE to 0x041A
(-50 to 1050)
Setting of OUT2 output set value
(Hysteresis)
2
R/W
H_2
(Setting of OUT1
hysteresis)
U16
50
Y
Setting range
0x0000 to 0x044C
(0 to 1100)
Setting of OUT2 hysteresis
(Hysteresis)
3
R/W
P2L (n2L)
(Lower limit of window
comparator)
S16
300
Y
Setting range
0xFFCE to 0x041A
(-50 to 1050)
Setting of OUT2 output set value
(Lower limit of window comparator)
4
R/W
P2H (n2H)
(Upper limit of window
comparator)
S16
600
Y
Setting range
0xFFCE to 0x041A
(-50 to 1050)
Setting of OUT2 output set value
(Upper limit of window comparator)
5
R/W
WH2
(Window comparator
hysteresis)
U16
100
Y
Setting range
0x0000 to 0x0226
(0 to 550)
Setting of OUT2 hysteresis
(Window comparator)
6
R/W
dtH2
(Delay time ON)
U16
0
Y
Setting range
0x0000 to 0x1770
(0 to 6000)
Setting of OUT2 delay time ON
10 ms increments
7
R/W
dtL2
(Delay time OFF)
U16
0
Y
Setting of OUT2 delay time OFF
10 ms increments
