Table 9: Header Connector Signals Channel 1
Pin #
Signal Name
Description
H1-1
DIO0_CH1
ISP Channel 1: Digital input/output 0
H1-2
DIO0_GND_CH1
ISP Channel 1: Digital input/output 0 Ground
H1-3
DIO1_CH1
ISP Channel 1: Digital input/output 1
H1-4
DIO1_GND_CH1
ISP Channel 1: Digital input/output 1 Ground
H1-5
DIO2_CH1
ISP Channel 1: Digital input/output 2
H1-6
DIO2_GND_CH1
ISP Channel 1: Digital input/output 2 Ground
H1-7
DIO3_CH1
ISP Channel 1: Digital input/output 3
H1-8
DIO3_GND_CH1
ISP Channel 1: Digital input/output 3 Ground
H1-9
DIO4_CH1
ISP Channel 1: Digital input/output 4
H1-10
DIO4_GND_CH1
ISP Channel 1: Digital input/output 4 Ground
H1-11
DIO5_CH1
ISP Channel 1: Digital input/output 5
H1-12
DIO5_GND_CH1
ISP Channel 1: Digital input/output 5 Ground
H1-13
DIO6_CH1
ISP Channel 1: Digital input/output 6
H1-14
DIO6_GND_CH1
ISP Channel 1: Digital input/output 6 Ground
H1-15
DIO7_CH1
ISP Channel 1: Digital input/output 7
H1-16
DIO7_GND_CH1
ISP Channel 1: Digital input/output 7 Ground
H1-17
VPROG0_CH1
ISP Channel 1: Programmable voltage 0
H1-18
VPROG0_GND_CH1
ISP Channel 1: Programmable voltage 0 Ground
H1-19
VPROG1_CH1
ISP Channel 1: Programmable voltage 1
H1-20
VPROG1_GND_CH1
ISP Channel 1: Programmable voltage 1 Ground
Table 10: Header Connector Signals Channel 2
Pin #
Signal Name
Description
H2-1
DIO0_CH2
ISP Channel 2: Digital input/output 0
H2-2
DIO0_GND_CH2
ISP Channel 2: Digital input/output 0 Ground
H2-3
DIO1_CH2
ISP Channel 2: Digital input/output 1
H2-4
DIO1_GND_CH2
ISP Channel 2: Digital input/output 1 Ground
H2-5
DIO2_CH2
ISP Channel 2: Digital input/output 2
H2-6
DIO2_GND_CH2
ISP Channel 2: Digital input/output 2 Ground
H2-7
DIO3_CH2
ISP Channel 2: Digital input/output 3
H2-8
DIO3_GND_CH2
ISP Channel 2: Digital input/output 3 Ground
H2-9
DIO4_CH2
ISP Channel 2: Digital input/output 4
H2-10
DIO4_GND_CH2
ISP Channel 2: Digital input/output 4 Ground
H2-11
DIO5_CH2
ISP Channel 2: Digital input/output 5
H2-12
DIO5_GND_CH2
ISP Channel 2: Digital input/output 5 Ground
H2-13
DIO6_CH2
ISP Channel 2: Digital input/output 6
H2-14
DIO6_GND_CH2
ISP Channel 2: Digital input/output 6 Ground
H2-15
DIO7_CH2
ISP Channel 2: Digital input/output 7
H2-16
DIO7_GND_CH2
ISP Channel 2: Digital input/output 7 Ground
H2-17
VPROG0_CH2
ISP Channel 2: Programmable voltage 0
H2-18
VPROG0_GND_CH2
ISP Channel 2: Programmable voltage 0 Ground
