34
Pin #
Signal Name
Description
H2-19
VPROG1_CH2
ISP Channel 2: Programmable voltage 1
H2-20
VPROG1_GND_CH2
ISP Channel 2: Programmable voltage 1 Ground
Table 11: Header Connector Signals Channel 3
Pin #
Signal Name
Description
H3-1
DIO0_CH3
ISP Channel 3: Digital input/output 0
H3-2
DIO0_GND_CH3
ISP Channel 3: Digital input/output 0 Ground
H3-3
DIO1_CH3
ISP Channel 3: Digital input/output 1
H3-4
DIO1_GND_CH3
ISP Channel 3: Digital input/output 1 Ground
H3-5
DIO2_CH3
ISP Channel 3: Digital input/output 2
H3-6
DIO2_GND_CH3
ISP Channel 3: Digital input/output 2 Ground
H3-7
DIO3_CH3
ISP Channel 3: Digital input/output 3
H3-8
DIO3_GND_CH3
ISP Channel 3: Digital input/output 3 Ground
H3-9
DIO4_CH3
ISP Channel 3: Digital input/output 4
H3-10
DIO4_GND_CH3
ISP Channel 3: Digital input/output 4 Ground
H3-11
DIO5_CH3
ISP Channel 3: Digital input/output 5
H3-12
DIO5_GND_CH3
ISP Channel 3: Digital input/output 5 Ground
H3-13
DIO6_CH3
ISP Channel 3: Digital input/output 6
H3-14
DIO6_GND_CH3
ISP Channel 3: Digital input/output 6 Ground
H3-15
DIO7_CH3
ISP Channel 3: Digital input/output 7
H3-16
DIO7_GND_CH3
ISP Channel 3: Digital input/output 7 Ground
H3-17
VPROG0_CH3
ISP Channel 3: Programmable voltage 0
H3-18
VPROG0_GND_CH3
ISP Channel 3: Programmable voltage 0 Ground
H3-19
VPROG1_CH3
ISP Channel 3: Programmable voltage 1
H3-20
VPROG1_GND_CH3
ISP Channel 3: Programmable voltage 1 Ground
Table 12: Header Connector Signals Channel 4
Pin #
Signal Name
Description
H4-1
DIO0_CH4
ISP Channel 4: Digital input/output 0
H4-2
DIO0_GND_CH4
ISP Channel 4: Digital input/output 0 Ground
H4-3
DIO1_CH4
ISP Channel 4: Digital input/output 1
H4-4
DIO1_GND_CH4
ISP Channel 4: Digital input/output 1 Ground
H4-5
DIO2_CH4
ISP Channel 4: Digital input/output 2
H4-6
DIO2_GND_CH4
ISP Channel 4: Digital input/output 2 Ground
H4-7
DIO3_CH4
ISP Channel 4: Digital input/output 3
H4-8
DIO3_GND_CH4
ISP Channel 4: Digital input/output 3 Ground
H4-9
DIO4_CH4
ISP Channel 4: Digital input/output 4
H4-10
DIO4_GND_CH4
ISP Channel 4: Digital input/output 4 Ground
H4-11
DIO5_CH4
ISP Channel 4: Digital input/output 5
H4-12
DIO5_GND_CH4
ISP Channel 4: Digital input/output 5 Ground
H4-13
DIO6_CH4
ISP Channel 4: Digital input/output 6
