Replacing the glass on an older Manual Call Point
&
Take appropriate precautions when clearing broken glass to prevent injury.
"
A weather resistant version of the manual call point may have two gaskets,
there may be a Cover/glass gasket and a there will be a Spacer/cover gasket, which must
be refitted in their respective positions.
71150-90NM-EN Spare MCP glass (Pack of 10)
These procedures assume the cover on the manual call point has been removed and any broken glass has
been cleared.
a. Feed the glass upward to push the cams down and fit it under the slider, locate bottom of glass into
recess.
b. Hold the bottom of glass in position and rotate the thumbwheel quadrant to raise the top of the glass.
c. Fit the call point cover by hooking it into the top of the unit, making sure that the glass is properly seated
(held down) tighten the cover fixing screw.
d. Test that the manual call point functions correctly.
31
