Attach the Y axes to the base plate.
05
/22
1:1
M5 × 12 Screw × 24
If you find it difficult to install the screws even following the tip above, check if the dowels of
the base plate are correctly inserted into the dowel holes of the Y axes.
It is recommended to pre-tighten the screws at the outermost corners first, then pre-tighten the
remaining screws, and finally tighten all the screws in the pre-tightening order.
