Make sure
the limit bars
of the profile
connectors are
inside the beam
grooves.
Make sure
all four
profile
connectors
are inside
up.
Attach the profile connectors to both ends of the long
beams.
02
/28
Profile Connector × 4
M5 × 12 Screw × 4
1:1
B1
