8.2 “MEASUREMENTS” menu.
This menu is used to display all the measurements relating to the UPS input, output and to the battery.
For models with single phase input or output, the voltage and current displays are adjusted automatically.
PRESENT MEASURES menu
Type of measurements Value Value Value Note
OUTPUT STAR VOLTAGE ___ V ___ V ___ V
OUTPUT LOAD __ % __ %
OUTPUT ACTIVE POWER ___ kW ___ kW ___ kW
OUT APPARENT POWER __._ kVA __._ kVA __._ kVA
OUTPUT CURRENT __._ A __._ A __._ A
OUTPUT FREQUENCY __._ Hz __._ Hz __._ Hz
AUXILIARY VOLTAGE ___ V ___ V ___ V
AUXILIARY FREQUENCY __._ Hz __._ Hz __._ Hz
INPUT STAR VOLTAGE ___ V ___ V ___ V
INPUT PH-PH VOLTAGE ___ V ___ V ___ V
INPUT FREQUENCY __._ Hz __._ Hz __._ Hz
INPUT APPARENT POWER __._ kVA __._ kVA __._ kVA
BATTERY VOLTAGE B1___ V B2___ V
BATTERY CAPACITY __ % Charging
BACKUP T___MIN Discharging
INTERNAL TEMPERATURE __ °C
BATTERY TEMPERATURE __ °C Only with a sensor present and set
8.2.1 “Statistical measurements” menu.
Once a (programmable) reference period has been de ned, the system reports measurements that are made avail-
able in digital or graphical format.
The values that are represented graphically can be used to analyse the situation over the last 24 hours. This informa-
tion, together with the programmed interval information, provides an enhanced evaluation on the operating mode
of the equipment in order to verify whether certain critical operating situations are repetitive or only casual.
STATISTICAL MEASUREMENTS menu
Measurement Value Option Option
INPUT APPARENT POWER MIN. AVERAGE MAX. ENTER displays ENTER displays
weekly graphics 24 hr graphics
BACKUP TIME LESS THAN 2 MINUTES NUMBER OF EVENTS
BACKUP TIME BETWEEN 2 AND 5 MINUTES NUMBER OF EVENTS
BACKUP TIME MORE THAN 5 MINUTES NUMBER OF EVENTS
OUTPUT LOAD MIN. AVERAGE MAX. ENTER displays ENTER displays
weekly graphics 24 hr graphics
OVERLOAD TIME LESS THAN 5 SECONDS NUMBER OF EVENTS
OVERLOAD TIME MORE THAN 5 SECONDS NUMBER OF EVENTS
REDUNDANCY LOST NUMBER OF EVENTS
INTERNAL TEMPERATURE MIN. AVERAGE MAX. ENTER displays ENTER displays
weekly graphics 24 hr graphics
BATTERY TEMPERATURE MIN. AVERAGE MAX. ENTER displays ENTER displays
weekly graphics 24 hr graphics
WORKING TIME ON GEN SET NUMBER OF HOURS
