ITALIANOENGLISH
50
IOMMASIPXX09-GB 04
10-40 kVA
MASTERYS IP+
11
OPTIONS
11.1 KIT GSS (GLOBAL SUPPLY SYSTEM).
To be installed on the slot “L”, this kit optimises generator sizing and control when connected to the UPS input.
The generator set can be instructed to start up automatically the moment the mains power is lost, or alternatively,
following a user-set time period without the mains power, and/or when the batteries have discharged to their
residual capacity.
11.2 ISOLATION CONTROLLER.
Installed on the DIN rail “F”, this device continually checks the transformer isolation, displaying an alarm message
on the mimic panel. The management of the option is possible via ADC card without temperature sensor (refer to
paragraph 3.9 “ADC card”)
11.3 REMOTE MIMIC PANEL.
This device monitors and interacts with the UPS through a serial link RS 485 (maximum distance of 175 m) 25 m
cable supplied standard; 50 m cable available as an option).
Legend.
A LAN RJ45 connector for Ethernet.
B Serial RS232 connector for Modem.
C Serial RS232/485 connector for after sales.
F DIN rail (under the panel)
L Slots for communication cards (ADC card
installed as standard, 1 slot available for an
additional card).
Masterys IP+ with battery.
Masterys IP+ without battery.
CBA
F
L
F
L
