ENGLISH
IOMMASIPXX09-GB 04
35
10-40 kVA
MASTERYS IP+
MENU
8
8.3 “COMMANDS” MENU.
This is used to send some immediate commands to activate the UPS or various operating modes. It can also be used
to send extended commands to de ne some UPS settings. To activate the commands select the command with
UP
or DOWN , press ENTER, select YES or NO to execute and press ENTER to con rm. The “Extended
controls” menu can only be seen if it is enabled in the menu CONFIGURATION.
IMMEDIATE COMMANDS menu
Command Description
START PROCEDURE UPS start-up command.
STOP PROCEDURE UPS shutdown command.
MAINTENANCE BY-PASS Control to activate the manual bypass and shutdown of the UPS.
PROCEDURE
HIGH EFFICIENCY MODE Activates Eco mode / always on mode.
NORMAL MODE Activates normal double conversion operation.
ALARM RESET Resets all the alarms.
LEDS TEST Performs the test on the mimic panel LEDs.
EXTENDED COMMAND menu
Command Description
MANUAL BATTERY TEST Activates the battery test.
BATTERY COMMISSION Activates battery commissioning (use only if necessary for the type of battery).
SET LAN DEFAULT VALUE Resets all the values of the LAN.
JBUS TUNNELING ENABLE Enables the connection of advanced software (BMS or Uni vision) via the LAN network.
JBUS TUNNELLING DISABLE
DHCP ENABLE Enables the automatic allocation of the IP address by the network server.
DHCP DISABLE
FORCE MODEM DIAL OUT Forces sending of an immediate test modem call.
DISABLE CHECK-UP Deactivates the periodic maintenance message.
