Chapter 1: Introducing the SolarEdge Control and Communication Gateway
Control and Communication Gateway Installation Guide - MAN-01-00132-1.2
10
Other Interfaces

DC: used for the power supply input as described in Connecting the SolarEdge Gateway to AC on
page 14.

Sensors: enables connecting to external environmental sensors (refer to Chapter 4: Connecting
Environmental Sensors (Optional) on page 22).

Control: used for connection to an external power reducer device

SW1/SW2: RS485-1/2 termination

Micro SD: used for field software upgrade
