Appendix A: Technical Specifications
Control and Communication Gateway Installation Guide - MAN-01-00132-1.2
46
Appendix A: Technical Specifications
Power
Description
Units
Power Supply wall mount
Included, 100240 VAC, EU/UK/US/AU
interchangeable 2-pin plug
Supply Voltage
9-14
Vdc
Connector Type
terminal block
Power Consumption
<2
W (typ.)
Analog Sensor Input
Number of Inputs
3
Range
Accuracy
Resolution
Input 1
02V or 010V
+/-1% f.s
10-bit
Input 2
030 mV or 02V
Input 3
-20 mA 20 mA
Communication Interfaces
Type
Max. Length
Ethernet Interface
10/100-BaseT
100/328
m/ft.
Wireless Connections
ZigBee module
(
*)
, Wi-Fi
(
*)
(**)
Power Reduction Interface
4 control pins, 5V, GND
50/165
m/ft.
RS232 Interface
For local connection
RS485 Interface
Two separate ports
1000/3330
m/ft.
Supported RS485 Devices
SolarEdge Devices
Yes
Revenue Meters
***
Yes
Export Inverter Data
Yes
Export Data to Non-SolarEdge Logger
Yes
Environmental
Operating Temperatures
-20 to 60 / -4 to 140
°C / °F
Protection Rating
IP20 Indoor
Mechanical
Mounting Type
DIN rail/ Wall mount
Dimensions (L x W x H)
161.6 x 90 x 62 / 6.36 x 3.54 x 2.44
mm / inches
Weight
< 0.5 / 1.1
kg / lbs
Standard Compliance
Safety
UL60950-1, IEC-60950-1
EMC
FCC Part 15 class B, IEC61000-6-2, IEC61000-6-3
* Sold separately. See individual product specifications for supported locations.
** EU only
*** For a list of recommended sensors and suppliers, refer to http://www.solaredge.com/articles/se-supported-devices.
