SE4K SE5K SE7K SE8K SE9K SE10K SE12.5K Unit
Additional Features
Supported
communication
interfaces
2 x RS485, Ethernet, Built-in GSM (Optional)
Inverter
commissioning
With the SetApp mobile application using built-in Wi-Fi
station for local connection
RS485 Surge
Protection
Optional
Smart Energy
Management
Export Limitation
Arc Fault Protection Integrated, user configurable (according to UL1699B)
Standard Compliance
Safety IEC-62103 (EN50178), IEC-62109
Grid connection
standards
(1)
VDE 0126-1-1, VDE-AR-N-4105, AS-4777, G83 / G59
Emissions
IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-
12,
FCC part15 class B
WEEE, RoHS Yes
Installation Specifications
AC output / Gland
Diameter / Wire Cross
Section
15-21 mm / Solid wire 2.5-16 mm
2
, Stranded wire 2.5 - 10
mm
2
DC input
2 MC4 pairs
(2)
Dimensions (WxLxH) 540 x 315 x 260 mm
Weight 33.2 kg
Operating
temperature range
(3)
-40 - +60 °C
Operating humidity –
non condensing
< 95 %
Cooling Fan (user replaceable)
(1)
For all standards refer to the Certifications category in
http://www.solaredge.com/groups/support/downloads.
(2)
You can connect strings in parallel to a single input as long as the cumulative current does not exceed 45A.
(3)
For inverter power de-rating refer to the application note at the following link:
http://www.solaredge.com/files/pdfs/se-temperature-derating-note.pdf
-Three Phase System Installation Guide MAN-01-00505-1.2
88 Technical Specifications - Three Phase Inverters (Europe &APAC)
Provided with the inverter in India only. For other countries an SPD plug-in can be purchased. Refer to
(4)
(4)
https://www.solaredge.com/sites/default/files/se_spd_plug_in_for_rs485_3ph_setapp_ds.pdf
