SolarEdge SE5K User Manual

SE4K SE5K SE7K SE8K SE9K SE10K SE12.5K Unit
Noise (typical)
< 50
(1)
dBA
Protection rating/
Environmental
category
IP65 - Outdoor and indoor
Maximum altitude 2000 m
Pollution degree
classification
(inside/outside)
2/3
Bracket mounted (bracket provided)
SE15K - SE33.3K
(2)
SE15K SE16K SE17K SE25K SE27.6K SE33.3K Unit
Output
Rated AC power
output
15000 16000 17000
25000
(3)
27600 33300 VA
Maximum AC power
output
15000 16000 17000 25000
6
27600 33300 VA
AC Output Line
Connections
 3 phase, 4-wire / PE (L1-L2-L3-N), TN, TT
AC output voltage –
line to line / line to
neutral (nominal)
380/ 220; 400/ 230 480/277 Vac
AC output voltage
range
184 – 264.5 244-305 Vac
AC frequency 50/60 ± 5 Hz
Maximum continuous
output current (per
phase)
23 25.5 26 38 40
40
@277V
A
Maximum continuous
overcurrent
protection
23 25.5 26 38 40 40 A
(1)
For inverters with a noise level suitable for residential environments refer to:
http://www.solaredge.com/files/pdfs/products/inverters/se-three-phase-indoor-inverter-
datasheet.pdf
(2)
The SE33.3Kmodel requires a medium voltage transformer.
(3)
24.99kVA in the UK
Technical Specifications - Three Phase Inverters (Europe &APAC) 89
Three Phase System Installation Guide MAN-01-00505-1.2

SolarEdge SE5K Specifications

General

Model	SE5K
Manufacturer	SolarEdge
AC Output Power	5000 W
Rated AC Power	5000 W
Max. Efficiency	98.3%
Cooling	Natural convection
Protection Rating	IP65
Max. Input DC Voltage	480 V
Max. Input Current	11 A
Number of MPP Trackers	1
Warranty	12 years
Communication Interfaces	RS485, Ethernet
AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
MPPT Voltage Range	330-480V
