SE15K SE16K SE17K SE25K SE27.6K SE33.3K Unit
Emissions
IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-
12
WEEE, RoHS Yes
Installation Specifications
AC output / Gland
Diameter / Wire Cross
Section
15-21 mm / Solid wire 2.5-
16 mm
2
,
Stranded wire 2.5 - 10
mm
2
18-25mm / Solid wire 2.5-16
mm
2
,
Stranded wire 2.5-10 mm
2
DC input
(1)
2 MC4 pairs 3 MC4 pairs
DC input with DC
Safety Unit
N/A
Gland diameter 5-10 mm mm
Wire cross section 0.5 - 13.5 mm
2
Dimensions (HxWxD) 540 x 315 x 260 mm
Dimensions with
Safety Unit (HxWxD)
N/A 775 x 315 x 260 mm
Weight 33.2 45 kg
Weight with Safety
Unit
N/A 48 kg
Operating
temperature range
(2)
-40 - +60 °C
Operating humidity –
non condensing
< 95 %
Cooling Fan (user replaceable)
Noise (typical) < 50 < 55 dBA
Protection rating/
Environmental
category
IP65 Outdoor and indoor
Maximum altitude 2000 m
Pollution degree
classification (inside/
outside)
2/3
Bracket mounted (bracket provided)
(1)
Connection of additional strings in parallel to a single input is allowed as long as the cumulative current does not
exceed 45A.
(2)
For inverter power de-rating information, refer to the application note at the following link:
http://www.solaredge.com/files/pdfs/se-temperature-derating-note.pdf
-Three Phase System Installation Guide MAN-01-00505-1.2
92 Technical Specifications - Three Phase Inverters (Europe &APAC)
